![Sika Sikasil 670 Fire Resistant Silicone Sealant [Grey]](http://gluesaustralia.com.au/cdn/shop/files/7612895181462_fe2d5a8d-2a66-433f-9d24-2dfa9adec11a.jpg?v=1754711694&width=645)
SIKASIL® -670 FIRE | JOINT SEALANT Fire-rated joint sealant Up to 4 hours fire resistance according to EN 1366-4 Very good resistance to weathering Easy to smooth and very good workability DESCRIPTION Sikasil®-670 Fire is a fire-rated, 1-component, moisture-curing, low-modulus elastic joint sealant. USES Sikasil®-670 Fire is designed for fire rated movement and connection joints on porous and non-porous substrates. CHARACTERISTICS / ADVANTAGES ▪ Up to 4 hours fire resistance according to EN 1366-4 ▪ Very good resistance to weathering ▪ Movement capability of ± 35% (ASTM C 719) ▪ Easy to smooth and very good workability ▪ Good adhesion to many different substrates ▪ Neutral curing ENVIRONMENTAL INFORMATION ▪ LEED® EQc 4.1 ▪ SCAQMD, Rule 1168 ▪ BAAQMD, Reg. 8, Rule 51 APPROVALS / STANDARDS ▪ EN 15651-1 F EXT-INT CC 25 LM ▪ EN 15651-4 PW INT ▪ ISO 11600 F 25 LM & G 25 LM ▪ ASTM C 920, class 35 ▪ EN 1366-4 assessment report ▪ ETAG 026 assessment report ▪ EN 13501-2 classification report ▪ EN 140-3 ▪ EN 13501-1 class B-s2-d0 PRODUCT INFORMATION Chemical Base Neutral cure silicone Colour: Grey Storage Conditions Sikasil®-670 Fire shall be stored in dry conditions, where it is protected from direct sunlight and at temperatures between +5 °C and +25 °C. Density 1.35 kg/l approx. (ISO 1183-1) TECHNICAL INFORMATION Shore A Hardness 16 approx. (after 28 days) (ISO 868) Secant Tensile Modulus 0.30 N/mm2 approx. at 100% elongation (23 °C) (ISO 8339) 0.50 N/mm2 approx. at 100% elongation (−20 °C) Elongation at Break 650% approx. (ISO 37) Elastic Recovery 70% approx. (ISO 7389) Tear Propagation Resistance 4.0 N/mm approx. (ISO 34) Movement Capability ±25% (ISO 9047) ±35% (ASTM C 719) Service Temperature −40 °C to +150 °C Joint Design The joint width must be designed to suit the joint movement required and the movement capability of the sealant. The joint width shall be ≥ 10 mm and ≤ 40 mm. The joint depth shall be ≤ 20 mm. A width to depth ratio of 2:1 must be maintained (for exceptions, see table below). Backing Material Use polyethylene foam backing rods. Sag Flow 2 mm approx. (20 mm profile, 50 °C) (ISO 7390) Ambient Air Temperature +5 °C to +40 °C, min. 3 °C above dew point temperature Substrate Temperature +5 °C to +40 °C Curing Rate 2 mm/24 hours approx. (23 °C / 50% r.h.) (CQP 049-2) Skin Time 25 minutes approx. (23 °C / 50% r.h.) (CQP 019-1) Tooling Time 20 minutes approx. (23 °C / 50% r.h.) (CQP 019-2) APPLICATION INSTRUCTIONS SUBSTRATE PREPARATION The substrate must be clean, dry, sound and homogeneous, free from oils, grease, dust and loose or friable particles. Sikasil®-670 Fire adheres without primers and/or activators APPLICATION METHOD / TOOLS Sikasil®-670 Fire is supplied ready to use. After the necessary substrate preparation, insert a suitable backing rod to the required depth and apply any primer if necessary. Insert a foil pack or cartridge into the sealant gun and extrude Sikasil®-670 Fire into the joint making sure that it comes into full contact with the sides of the joint and avoids any air entrapment. Sikasil®-670 Fire sealant must be firmly tooled against the joint sides to ensure adequate adhesion. It is recommended to use masking tape where exact joint lines or neat lines are required. Remove the tape within the skin time. Do not use tooling products containing solvents. CLEANING OF TOOLS Clean all tools and application equipment immediately after use with Sika® Remover-208 and/or Sika® TopClean T. Once cured, residual material can only be removed mechanically. FURTHER DOCUMENTS ▪ Safety Data Sheet (SDS) ▪ EN 13501-2 classification report ▪ ETAG 026 assessment report ▪ Brochure Sika Fire Protection Solutions LIMITATIONS ▪ Sikasil®-670 Fire cannot be overpainted. Colour variations may occur due to exposure to chemicals, high temperatures and/or UV-radiation (especially with the colour shade white). However, a change in colour is purely of aesthetic nature and does not adversely influence the technical performance or durability of the product. ▪ Do not use Sikasil®-670 Fire on natural stone. Do not use Sikasil®-670 Fire on bituminous substrates, natural rubber, EPDM rubber or on any building materials which might bleed oils, plasticizers or solvents that could attack the sealant. ▪ Do not use Sikasil®-670 Fire to seal joints in and around swimming pools. ▪ Do not use Sikasil®-670 Fire for joints under water pressure or for permanent water immersion. ▪ Do not expose uncured Sikasil®-670 Fire to alcohol-containing products as this may interfere with the curing reaction.
$22.15
![Sika SikaSil 670 Fire Rated Silicone Sealant [Grey]](http://gluesaustralia.com.au/cdn/shop/files/9318324012236_d7a5d83c-0ea4-4a46-88bb-55e873bf5a05.jpg?v=1754711696&width=645)
Usage Sikasil®-670 Fire is designed for fire rated movement and connection joints on porous and non-porous substrates. Advantages Up to 4 hours fire resistance according to AS 1530.4 Up to 4 hours fire resistance according to EN 1366-4 Very good resistance to weathering Movement capability of ± 35% (ASTM C 719) Easy to smooth and very good workability Good adhesion to many different substrates Neutral curing Colour Grey
$27.35
Sika Firerate is a gunnable acrylic based jointing and sealing compound specially formulated with inorganic fillers to provide a fire barrier. Sika Firerate has been tested for fire resistance for up to 4 hours according to AS 1530.4 in masonry wall and floor joints. USE Sika Firerate is suitable for sealing joints in concrete or masonry that must have a fire rated resistance to Australian Standards. Sika Firerate also fulfils the basic function of a gap filler and joint sealant against water and dust penetration. CHARACTERISTICS AND ADVANTAGES Safe to use – contains no asbestos or fibres. Paintable. Good flexibility and adhesion to concrete and masonry. Interior use only. Easily applied with normal caulking equipment. Easy tooling off. Economical – single product for both fireproofing and sealing functions. Water clean-up of tools and equipment while still uncured. Excellent acoustic performance, test report available. COLOUR Grey CHARACTERISTICS/ADVANTAGES • Up to 4 hours fire resistance according to AS 1530.4 • Very good resistance to weathering • Movement capability of ± 20 % • Easy to smooth and very good workability • Good adhesion to many different substrates • Water clean-up of uncured sealant . APPROVALS / STANDARDS • AS 1530.4 FRL • ISO 717.2 Rw (Ctr) = 64 (-13) SUBSTRATE PREPARATION The substrate must be clean, dry, sound and homogeneous, free from oils, grease, dust and loose or friable particles. Sika® Firerate adheres without primers and/or activators. APPLICATION METHOD / TOOLS Sika® Firerate is supplied ready to use. After the necessary substrate preparation, insert a suitable backing rod to the required depth and apply any primer if necessary. Insert a foil pack or cartridge into the sealant gun and extrude Sika® Firerate into the joint making sure that it comes into full contact with the sides of the joint and avoids any air entrapment. Sika® Firerate sealant must be firmly tooled against the joint sides to ensure adequate adhesion. It is recommended to use masking tape where exact joint lines or neat lines are required. Remove the tape within the skin time. Do not use tooling products containing solvents. Water can be used if wet tooling is required. CLEANING OF TOOLS Clean all tools and application equipment immediately after use with water. Once cured, residual material can only be removed mechanically LIMITATIONS • Sika® Firerate may be overpainted with solvent free paints. • Do not use Sika® Firerate on damp and/or wet substrates. • Do not apply Sika Firerate at temperatures below 5ºC • Do not use Sika® Firerate to seal joints in and around swimming pools. • Do not use Sika® Firerate to seal joints in external applications on non-porous substrates. • Do not use Sika® Firerate for joints under water pressure or for permanent water immersion. • Do not expose uncured Sika® Firerate to rain or water as this may interfere with the curing reaction. BASIS OF PRODUCT DATA All technical data stated in this Data Sheet are based on laboratory tests. Actual measured data may vary due to circumstances beyond our control. ECOLOGY, HEALTH AND SAFETY For information and advice on the safe handling, storage and disposal of chemical products, users shall refer to the most recent Safety Data Sheet (SDS) containing physical, ecological, toxicological and other safety related data.
$25.69
Selleys FlameFlex is a fire and acoustic rated sealant with outstanding product performance. Features Fire rated up to 4 hours according to AS1530.4# Complies with BCA acoustic requirements# Superior UV resistance Suitable for interior and exterior use No primer required before painting Adhesion to wet or damp surfaces Better curing (>5°C) Non-bubbling Paintable with water-based paints after product skins in 60 to 90 minutes (apply paint within 12 hours of sealant application) Low VOC – so can be used in any environment without discomfort Where can this product be used? Perfect for use on and around: Sky lights Walls Patios Windows Expanding joints in concrete What materials is this product suitable for? Concrete Timber Metals Cement sheeting Brick Plasterboard Ceramic tiles Fibreglass Most plastics (Pre-test before use. Not for polyethylene, polypropylene or Teflon.) How to use this product Ensure substrates are clean and free of oil, grease or loose particles. Cut seal and nozzle and fit to the cartridge, then place in the caulking gun. Hold caulking gun at 45 angle and gun sealnt ahead of nozzle ensuring product is pushed into joint. For neat joints, use masking tape on both sides of the joint and remove before skinning. Tool with a soapy solution before skinning occurs. For optimal joint design, use non-absorbent backing material (e.g. polyethylene backer rod) and appropriate joint width/depth. See technical data sheet for more information. Storage and re-use Product has a 12 months shelf life when stored unopened, in dry and cool conditions Use within 6 months after opening Clean up Uncured sealant can be removed with Mineral Turpentine Safety tips Not suitable on polyethylene, polypropylene or Teflon. Cure excess product before disposal. Avoid skin and eye contact and inhalation of vapour. If in eyes, wash out immediately with water. If skin contact occurs, wipe off immediately and wash with running water. Ensure use in a well ventilated area. Additional information is provided in the Safety Data Sheet. Product Information Selleys FlameFlex™ is available in Grey in a 435g cartridge. Uses This fire and acoustic rated joint sealant has high UV resistance and can be used indoors and outdoors on most surfaces. External and internal, non-trafficable control joints in concrete, masonry, AAC and brick fire rated construction. Acoustic sealing between most common building materials such as concrete, masonry, aerated concrete, plasterboard, fibre cement, metals, timber and plastic as part of a suitable design. Installation over a wide temperature range High UV exposed applications Technical Features Fire rated up to 4 hours according to AS1530.4 Complies with BCA acoustic requirements No primer required Adhesion to wet surfaces Better curing (>5°C) Non-bubbling Better extrudability (>5°C) No slump Paintable Low VOC Halogen free Isocyanate free How To Use The following should only be used as a guide and the installer should apply all Australian Standards, BCA/NZBC requirements, and best practices when using FlameFlex™. Surface Preparation: Ensure surfaces are clean and free of oil, grease, release agents, dust or loose particles. Porous surfaces should be prepared by grinding, brushing, wiping with cloths or blowing off with oil-free compressed air. Any laitance should be removed from concrete- based surfaces. Non-porous surfaces should be free of scale, rust or oxides and can be degreased with a solvent such as MEK, acetone or mineral turpentine. Some degreasing solvents may leave a residue that should be removed. For neat joints use masking tape on both sides of the joint and remove before skinning Joint Design: Refer to separate section. Cartridge: Cut tip and attach nozzle. Insert in the caulking gun. Cut nozzle to the size required for joint. Application: Extrude sealant smoothly into the joint, while ensuring that all substrates are well wetted out with sealant. Curing: The sealant cures by reaction with atmospheric moisture; therefore cure rate is dependent on humidity, ambient temperature and joint size. Typically, the sealant will form a thick skin within 24 hours and full cure can be expected after 7 days. In dry or cool conditions the sealant cure will be longer. Painting: Paintable with water-based paints after product skins (60 – 90 min). Allow longer times before painting in colder weather. Paint within 12 hours of application. Solvent-based paints may be used after first painting with a water-based paint. Due to a large number of paints and varnishes available, a preliminary test of compatibility is recommended. Joint Design For fire rating, joint width should be between 20mm and 40mm. Minimum joint depth should be 10mm or half the width for joints wider than 20mm. A tight-fitting non-absorbent, non-adhering backing material should be used to ensure the correct dimensions and prevent three-surface adhesion. Suitable materials include open cell foam backer rod or bond-breaking tape. Clean Up The uncured product can be removed with mineral turpentine. Cured product can be removed by mechanical action. Use Poly Cleaning Wipes to remove sealant from the skin. Handy Hints In dry conditions, surfaces can be misted with water to speed up cure. Limitations Not for permanent water immersion or below water-line use Not suitable for use on polyethylene, polypropylene or Teflon.
$26.52
Features Resists intense heat Sets hard Water clean up Where can this product be used? Repairing bricks in fireplaces and chimneys Sealing flues in pot-belly stoves Filling cracks in ironworks and bricks What materials is this product suitable for? Brick Metal Concrete How to Use: Remove all dust, grease and loose debris before applying material. Dampen the cavities on porous surfaces for better adhesion. Apply Fireproof Cement firmly into holes and cracks with a damp knife or spatula. Allow Fireproof Cement to dry a minimum of 48 hours before exposure to heat. If Fireproof Cement is stiff slacken with a little water. Limitations: Fireproof Cement is not an adhesive - it is a filling compound. Not recommended for external use e.g. BBQ's, incinerators etc. Fireproof Cement is not suitable for use in kilns. Fireproof Cement is not recommended for moving joints such as expansion joints as it sets rigidly Hardened material cannot be resoftened with water.
$49.46
Products with fire-resistant or fire-retardant claims for use in systems requiring enhanced flame performance. May include intumescent, low-smoke or self-extinguishing properties—check the declared classification or tested standard on the product page. Match the product to your substrate and joint design, and follow specified film thickness or bead size. Use filters to refine by chemistry and application method. Always consult the TDS/SDS and any compliance notes before use.
